Re45 Dual-light Fusion Thermal Imaging Night Vision Device (with Video Recording Function)
Onick RE45 (with video recording function) This is a dual-light fusion thermal imaging night vision device with video recording function. It adopts infrared and low-light fusion, combining the advantages of infrared and low-light, making the imaging resolution higher, the single body easier to be identified, and solving the defect that single infrared cannot pass through glass.
€0
Product Details
Product Details
Dual-light fusion thermal imaging night vision device
Onick RE45 (with video recording function) This is a dual-light fusion thermal imaging night vision device with video recording function. It adopts infrared and low-light fusion, combining the advantages of infrared and low-light, making the imaging resolution higher, the single body easier to be identified, and solving the defect that single infrared cannot pass through glass. At the same time, it has a new fusion focus (picture-in-picture) function, which can magnify a single point and maintain a high clarity.
The main feature of the dual-light fusion thermal imaging night vision device of Onick RE45 (with video recording function) is the face recognition function. Ordinary thermal imagers can only see blurry human figures, while Onick RE45 dual-light fusion thermal imaging night vision device can see the face clearly and know the real face. It is a dual-light fusion product that combines thermal imagers and night vision devices. The ranging function is based on the electronic compass and azimuth ranging inside. And you can know the direction of the target point, which does not refer to laser ranging. Onick RE 45 has a test report issued by the Quality Inspection Center for Security and Police Electronic Products of the Ministry of Public Security, which can be checked and verified on the official website of the Quality Inspection Center of the Ministry of Public Security!
Product features:
1. Switch between multiple high-definition imaging modes at will;
2. Four-fold fusion optical zoom, automatic tracking of infrared hotspot targets;
3. Distance measurement, photo taking, video recording, maximum support for 32G storage;
4. Six cross cursors, compact structure, low energy consumption, and long battery life;
5. 8-14μm high-sensitivity long-wave infrared imaging, 0.4-1.2μm low-light imaging/2k resolution;
6. Infrared and low-light dual-channel fusion, shutter-free thermal imaging, electronic compass, small and flexible, easy to carry.
Inspection report approved by China and internationally recognized: Inspection report of the Quality Inspection Center for Security and Police Electronic Products of the Ministry of Public Security, Beijing Inspection No. 1910270.
Dual-light fusion observation is mainly used in:
Public security, special police, armed police, security, technical investigation, protection, drug control, electricity, procuratorate, forestry, firefighting, maritime, industry, electronics, medical treatment, scientific research, security and anti-smuggling, border defense, reconnaissance, culvert detection, wildlife protection and border and coastal defense and other fields.
| model | Onick RE45 with Video recording | ||
| infrared | Infrared thermal imaging channel | Vanadium oxide detector，8 um～14 um ，17um，384×288，<50mK @F/1.0，30Hz | |
| Field Angle | 17°×13° | ||
| shutter | Shutter-free adaptive scene correction | ||
| shimmer | Low-light imaging channel | 0.4 um～1.2um ，2048x2048，<0.0001Lux，30Hz | |
| Field Angle | 10°×7° | ||
| system performance | Image mode | Thermal image band/Infrared pseudo-color/low-light band/Fusion thermal image/Fusion Pseudo-color/Fusion focus (picture in picture) | |
| Focus Distance | 21mm | ||
| Optical zoom | 4x optical zoom picture in picture | ||
| Intelligent algorithm | Fusion hotspot target automatic tracking | ||
| Brightness/contrast | Manual/Fully automatic | ||
| Image enhancement | Fusion through fog enhanced | ||
| Image shooting | Tap to capture an image/Hold down to record an image | ||
| Image storage | Built-in 32GSD card | ||
| Image download | USB | ||
| Video display | Support PAL analog display | ||
| Built-in display | 720x540、LCOS | ||
| Electrical interface | Power supply, USB, analog video | ||
| Mechanical interface | 1/4 inch tripod | ||
| charging | USB power adapter 5VDC | ||
| Battery duration | ≥6h | ||
| Fusion imaging range | Fusion imaging: 1.8x0.5m person; Detection ≥4000m, identification ≥1500m | ||
| Electronic compass | support | ||
| Three-dimensional attitude | support | ||
| Fusion image ranging | support | ||
| physical properties | weight | ≤500 g | |
| dimension | ≤175mm×88mm×50mm | ||
| Operating temperature | -20℃～+60℃ | ||
| Storage temperature | -40℃～+60℃ | ||
| qualification certificate | Ministry of Public Security and police electronic product quality testing center inspection report | ||
| product feature | Infrared and low light dual channel fusion, no shutter thermal image, electronic compass, small and flexible, easy to carry | ||
